Build the SeaDAS Science Processing Code

View step-by-step instructions to build the science processing software used within NASA's Ocean Biology Processing Group.

This page contains the science processing software used within NASA's Ocean Biology Processing Group (OBPG). They are provided here with no support. For fully supported code, please use the binaries distributed with the Sea, earth, atmosphere Data Analysis System (SeaDAS) application.

OCSSW_bash.env (OCSSW.env for csh) is provided for setting the environment variables needed to build the software.

Requirements

  • gcc (8 or higher, we use 10)
  • g++ (matching gcc version)
  • gfortran (matching gcc version)
  • zlib
  • csh
  • unzip
  • git
  • cmake
  • bison
  • flex
  • wget
  • Python3 (we use 3.12)

Additional Known OS-Specific Requirements

  • Ubuntu 20.04
    • zlib1g-dev
    • libX11-devel
  • CentOS 7
    • glibc-static
    • libgfortran-static
    • zlib-static
    • gmp-static
    • libjpeg-turbo-static
    • libstdc++-static
  • Mac
    • use homebrew to install gcc and such
    • libX11 can be installed by XQuartz

Building the Code

CMake is used for the build system with a CMakeLists.txt file in each directory.

Here are the steps needed to build using bash, cmake, and make:

1. Get a copy of the OCSSW source git repository

git clone git@git.smce.nasa.gov:oel/ocssw.git [optional target directory name]
cd ocssw
git submodule init
git submodule update

2. Setup environment variables (usually in ~/.bashrc)

export CC=gcc
export CXX=g++
export FC=gfortran
export OCSSWROOT=$HOME/ocssw
export OCSSW_DEBUG=1 #set to 0 if not debugging
source $OCSSWROOT/OCSSW_bash.env

3. Grab the third party library sources (opt/src)

- Make sure $OCSSWROOT is set properly

- Now grab opt/src

cd $OCSSWROOT
./get_lib3_src.sh

4. Build and install the third party libs

cd $OCSSWROOT/opt/src
export OCSSW_DEBUG=0 #probably do not want debug set for these
./BuildIt.py clean
./BuildIt.py

5. Create build directory and run cmake

CMake allows for out-of-source-tree builds. Make a directory for this and run cmake within it

cd $OCSSWROOT
mkdir build
cd build
cmake ..

Note: There are a few options you can give to cmake to control what extra software is built:

BUILD_HISTORICAL - Build the historical code (e.g. old seawifs binaries no longer needed)
BUILD_MISC - Build non-essential code
BUILD_AHMAD_FRASER - Build the AF radiative transfer code (not distributed)
USE_MPI - Set definition to use MPI (also set by OCSSW_MPI env variable)
BUILD_ALL - Build everything we got

The "cmake .." command is run like this to use one or more of these options:

cmake .. -DBUILD_HISTORICAL=ON -DBUILD_MISC=ON

Please be aware that not all the code required for these options is available in the externally accessible source repository.

6. Build the OCSSW binaries

cd $OCSSWROOT/build
export OCSSW_DEBUG=1 #could be set to 0 if not debugging
make -j 20

7. Install binaries into $OCSSWROOT/bin

make install

8. Grab the data tree.

This will download 280Gig and only has to be done once. You have a choice here to only install a few sensors if you do not want everything. if you are not using --all then you have to have at least --common, --ocrvc and --luts

install_ocssw --tag `cat $OCSSWROOT/.manifest_tag` --all

9. Update the data tree

This can be done to update the data tree to the proper tag after a new git checkout. The proper tag for the code in the OCSSW repository is stored in $OCSSWROOT/.manifest_tag. This command will only update sensor directories that are already installed. It also updates the LUTs in $OCSSWROOT/var.

cd $OCSSWROOT/build
make update

Command Line Autocomplete

We have auto complete definitions for many of the OCSSW programs.

1. For bash

source $OCSSWROOT/src/scripts/autocomplete_bash.sh

2. For zsh

source $OCSSWROOT/src/scripts/autocomplete_zsh.sh

IDE setup

Use MS Visual Studio Code for Programming and Debugging

Here are the steps needed to use VS Code for programming and debugging:

1. Install OCSSW as described above

2. In VSCode "Open Folder" $OCSSWROOT

3. When prompted, install C++ extensions and select the gcc-9 compiler

Use NetBeans for Programming and Debugging

Here are the steps needed to use NetBeans for programming and debugging:

1. Download, build, and install OCSSW as described above. Make sure to set `OCSSW_DEBUG=0` before building 3rd party libs and setting `OCSSW_DEBUG=1` before building OCSSW code.

2. Setup the correct compilers

  • Menu Tools -> Options
  • Select C/C++
  • Select Build Tools tab
Base Directory = /usr/bin
C Compiler = /usr/bin/gcc-5
C++ Compiler = /usr/bin/g++-5
Fortran Compiler = /usr/bin/gfortran-5
Assembler = /usr/bin/as
Make Command = /usr/bin/make
Debugger Command = /usr/bin/gdb
QMake Command = /usr/bin/qmake
CMake Command = /usr/bin/cmake
  • Click OK

3. Load the project into netbeans

  • Menu File -> New Project
  • Select C/C++
  • Select C/C++ Project with Existing Sources
  • Click Next

Folder that contains existing source = $OCSSWROOT

(substitute the real dir for $OCSSWROOT)

Build Host = localhost
Tool Collection = Default GNU
Configuration Mode = Custom
  • Click Next
  • Check Pre-Build Step is Required
  • Run in Folder = $OCSSWROOT/build
  • Select Predefined Command
Script type = CMake
Script = $OCSSWROOT/CMakeLists.txt
Arguments = (the default is fine)
  • Click Next
(Build Actions)
  • Click Next
(Source Files)

Source File Folders = $OCSSWROOT

(Exclude Pattern)
^(nbproject|.git|opt|share|test|var)$
  • Click Next
(Code Assistance Configuration)
  • Click Next
(Project Name and Location)
  • Click Finish

4. Setup a run configuration

menu Run -> Set Project Configuration -> Customize...

  • Click Manage Configurations...
  • Click New

New Name = l2gen (or whatever you want)

  • Select l2gen
  • Click Set Active
  • Click OK

Select Categories: Build -> Make

Working Directory = build
Build Command = ${MAKE} -j 20
Clean Command = ${MAKE} clean
Build Result = build/src/l2gen/l2gen

Select Categories: Run

Run Command = "${OUTPUT_PATH}" par=S2002079035435.L2_MLAC_OC.subpix.par
Run Directory = $OCSSWROOT/test/l2gen/seawifs
Environment =
Build First = checked
Console Type = Internal Terminal
External Terminal Type = Default
  • Click OK

Now you can run or debug.

5. Setup OBPG standard code formatting style

  • Select menu Tools->Options
  • Select "Editor" icon on top
  • Select "Formatting" tab
  • Make sure "Language: All Languages"
  • Check "Expand Tabs to Spaces"
  • Number of spaces = 4
  • For each language (C, C++, C/C++ Headers) change
  • Select Style = K&R
  • Under "Braces Placement" heading
  • Function Declaration = Same Line

Use Eclipse for Programming and Debugging

Here are the steps needed to use eclipse for programming and debugging:

1. Download, build and install OCSSW as described above. Make sure to set `OCSSW_DEBUG=0` before building 3rd party libs and setting `OCSSW_DEBUG=1` before building OCSSW code.

2. Load the project into eclipse

  • Menu File -> New -> C++ Project Project Name:
  • Make up a name for the project
  • Uncheck Use Default
Location Location = $OCSSWROOT (substitute your val for $OCSSWROOT)

Project type:

Makefile Project -> Empty Project

Toolchains = "Linux GCC" for Linux, "MacOSX GCC" for mac

Next Advanced Settings (button)

C/C++ Build (list item)

Builder Settings (tab)

  • Uncheck "Use default build command"
Build Command = make -j 20
  • Uncheck "Generate Makefiles automatically"
Build Location = ${workspace_loc:/ocssw/build}
  • Click on the OK Button.
  • Click on the Finish Button.

Wait a long time for the C/C++ Indexer to finish...

3. Make a run configuration to run l2gen

  • Menu Run -> Run Configurations...
  • Select C/C++ Application
  • Click the icon with a plus sign on it
  • Name = l2gen-run
Main tab C/C++ Application = build/src/l2gen/l2gen
Arguments tab Program arguments = "par=S1997262224952.L2_LAC.par"
  • Uncheck Use default
Working directory = $OCSSWROOT/test/l2gen (substitute your value)
  • Click Apply
  • Click Run

4. Setup OBPG standard code formatting style

Menu Window -> Preferences General -> Editors -> Text Editors Display tab

width = 4

  • Check "Insert spaces for tabs"

C/C++ -> Code Style -> Formatter click "New..." button

Profile name = OCSSW Initialize settings with following profile: K&R [built-in]

  • Click OK

Indentation Tab Policy

Spaces only

Indentation size = 4

Tab size = 4

Braces tab Function declaration: Same Line

Line Wrapping tab check "Never join already wrapped lines"

  • Click OK
  • Click Apply
  • Click OK
